This is to notify you of Terminal connector change of High-speed Digital panel meter AM-763
because of the current connector has discontinued.
■Products
1）AMH-763-VA-11-□ (Display only)
2）AMH-763-VA-15-□ (RS-485 output)
3）AMH-763-VA-17-□ (Analog output)
■Changes
We will change Intermediate terminal (12 pins).
There is no change in the wiring, but you cannot attach current product’s connector to the changed product.
Current product | Changed product | |
|---|---|---|
| Manufacturer | Sato Parts | Phoenix Contact |
| Housing Material | PBT (Polybutylene terephthalate) | PA (Polyamide) |
| Color | Gray | Green |
| Applicable wire (single wire) | φ0.4mm～φ1mm (26～18AWG) | Same as the left |
| Applicable wire (Stranded wire) | 0.3mm2～0.75mm2 (22～20AWG) | Same as the left |
(a) Current product
(b) Changed product
■Changing date
We will change to the new connector as soon as the stock of the current product has run out.
It is expected to be after October, but please notice that connector may change earlier than due date depending on
the order status.
